h-mnt-1.jpg 978 hits | 36.98 KB | Posted: 7/18/05 Initial fit up - Front view
I actually had all these items just lying around my shop.
Well, not the camcorder.
That's a metal pipe with plastic end from an old umbrella stand.
h-mnt-5.jpg 951 hits | 51.14 KB | Posted: 7/18/05 Note the vacuum fittings to cover up the U-Bolt ends.
After all is said and done, SCCA requires a strap between the camera and the mount to secure it in case it falls off.
Keep posted for pics of that once I get it done.
h-mnt-3.jpg 891 hits | 36.26 KB | Posted: 7/18/05 Camera Mount:
1/4 X 20 stud.
1" thin rubber washer and 1" fender washer directly under the camera.
The rest is pretty self explanatory.
h-mnt-4.jpg 746 hits | 44.01 KB | Posted: 7/18/05 All painted up nice and pretty.
Don't worry about that pointy soft plastic end.
It sits about 6" behind my seat back.
I will probably find a "safer" looking plug though.
