psomdisplaytest.jpg Odometer Display Self-Test

1 - Press and hold the reset button on the front of the speedometer while turning the key to RUN.

2 - Release the RESET button.

3 - Press and release the select button. The odometer will begin with all zeroes and step through the display test each time the select button is pushed. Refer to PSOM Display Test Sequence diagram for exact display.

* The first digit on the left does not always match the other digits.

4 - Key off to exit this test.

If the odometer display alternately flashes the miles and "ERROR 3", the conversion constant has been lost and needs to be re-programmed, as described in this caption:

[url=https://www.supermotors.net/registry/media/76023][img]https://www.supermotors.net/getfile/76023/thumbnail/cluster-front.jpg[/img][/url]

[url=https://modulemechanics.com/product/f4uf-10d922-ba-replacement-lcd-for-1992-1997-ford-psom-odometer-screen-display/]New odo display[/url] ~$90
psomdisplaytest.jpg | Hits: 10546 | Posted on: 3/21/07 | View original size (48.98 KB)

Odometer Display Self-Test

1 - Press and hold the reset button on the front of the speedometer while turning the key to RUN.

2 - Release the RESET button.

3 - Press and release the select button. The odometer will begin with all zeroes and step through the display test each time the select button is pushed. Refer to PSOM Display Test Sequence diagram for exact display.

* The first digit on the left does not always match the other digits.

4 - Key off to exit this test.

If the odometer display alternately flashes the miles and "ERROR 3", the conversion constant has been lost and needs to be re-programmed, as described in this caption:



New odo display ~$90
