warnoeman.jpg Stock (Warn) Manual Hub Locks
IF THE IMAGE IS TOO SMALL, click it.

This diagram has errors & omissions.  The axle stub shaft retainer is not shown.  For 1/2-ton (5-lug) trucks, the brake rotor attaches to the rear (inboard face) of the hub flange by the lug studs' splines.

Ford 8.8" axle uses 10 lug studs D6AZ-1107-A ('83-00)
Dana 44IFS uses 10 lug studs D6TZ-1107-A ('83-96)
Ford TIB axle uses 10 lug studs F4UZ-1107-A ('94-96)
warnoeman.jpg | Hits: 6601 | Posted on: 11/9/11 | View original size (326.28 KB)

Stock (Warn) Manual Hub Locks
IF THE IMAGE IS TOO SMALL, click it.

This diagram has errors & omissions. The axle stub shaft retainer is not shown. For 1/2-ton (5-lug) trucks, the brake rotor attaches to the rear (inboard face) of the hub flange by the lug studs' splines.

Ford 8.8" axle uses 10 lug studs D6AZ-1107-A ('83-00)
Dana 44IFS uses 10 lug studs D6TZ-1107-A ('83-96)
Ford TIB axle uses 10 lug studs F4UZ-1107-A ('94-96)
