79 Dana 44

I'll use this stuff to make some size tall jack stands

32" tall

Some last pics of what remains of a 6" TTB Superlift

Let the games begin

Dane giving me a hand

New James Duff 15" travel shocks

Side by side with Bilstein 10" travel shocks

mocked up with radius arms and driveline so I can determine how long to extend the radius arms

radius arms in for a test fit

getting ready to cut the factory engine crossmember

here's the crossmember and the old TTB mounting bracket cut off and ready for paint

finshed radius arms bolted up!

I used a laser to make sure the axle was aligned

tires on ready to work on steering and track bar

tapping the tie rod

tie rod in, I am using ratchet straps to hold the axle in place under the truck so it can sit on the tires and stay in the correct place to measure for my track bar

I used the factory trackbar mount from a 79 Bronco, with some modifications

test fit

track bar mount tack welded in place, notice the hole I had to drill to access the steering box bolt

checking track bar before final welding

track bar with weld in bungs

finished trackbar mount

I had to extend the shock mounts to allow for 15" travel shocks

rear 15" travel shocks
