1991 Ford Bronco
Owner: |
Ruff414 |
From: |
Central Oahu, HI, U.S.A. (Other registries in HI) |
Year, Make, & Model: |
1991 Ford Bronco (Other Ford Broncos) |
Avatar: |
|
Nickname: |
Pono |
Mileage: |
|
Engine: |
414 STROKER
ENGINE BUILDER:
Dan Strezo of DLS Engine Development, Wheatfield, Ind.
BLOCK:
SVO M-6010-W351 siamese bore, 4 bolt race block
DLS 4340 forged 4 in. stroke crank
DLS 4340 forged rods w/ F.M. bearings
DLS custom forged pistons w/double pin oilers and file fit rings
DLS H.D. wrist pins
DLS custom fabricated kick out oil pan w/ custom oil pump pick
up and oiling
Melling oil pump
ARP main studs
Professional Products harmonic balancer
JBG Super Duty Poly Motor Mounts
Remote oil filter mount, AN fittings w/ SS braided hoses (no filter
mount on block)
Deburr and prepped block for machining, align-honed mains
w/studs, decked block to spec w/deck tru, bored cylinders w/bore
tru, honed w/ plates and studs, moch ass. fit for rod circ., balanced
assembly. Block painted gray.
CAM:
DLS Custom Grind Roller Cam (only Dan knows specs)
Hydraulic roller lifters
Billet roller timing set
Billet cam washer and bolt
Coated cam bearings
HEADS:
DLS race prepped Edelbrock Victor Jr.
Comp Cams rocker arms
Comp Cams rocker studs
Comp Cams valve springs and 10 deg. locks
Comp Cams stud girdle
DLS custom length push rods
ARP head studs
Ford Racing valve covers w/ Moroso breathers
Autolite plugs
INTAKE:
DLS custom Edelbrock Victor converted to EFI
4150 4 Barrel throttle body
1 inch throttle body spacer
Lokar throttle cable
Lokar spring return kit
14 in. spun aluminum drop base air cleaner housing
COOLING:
Custom Ron Davis 31x19 Off Road Double Pass radiator
Dual 14 inch shrouded Spal fans
Spal 185 degree dual fan relay harness kit
Custom welded mounts by Jason and Margo at Kat's General
Repair in Honolulu
Ford Racing aluminum water pump
Stainless steel radiator hoses
Meziere water neck
FUEL:
Walbro 255 lph in-tank pump
Wilson Manifolds fuel rails
Aeromotive fuel press. regulator and gauge
Earl's Performance Ano-Tuff Swivel-Seal anodized hose ends w/
SS braided hose
42# Injectors
IGNITION:
MSD Pro-Billet Distributer
MSD coil
MSD 6A Ignition
Wilson Manifolds billet distributor hold down
Comp Cams Carbon Ultra-Poly Drive Gear
MSD 8.5mm wires
EXHAUST:
Stan's Headers Tri-Y w/ 1 5/8 in. primaries, 2 inch
secondaries, 2 1/2 in. ball/cone collectors
2 1/2 in. Mandrel bent dual exhaust w/ X-Pipe
Spintech 2 1/2 in. Super Pro Street mufflers.
ELECTRICAL:
RJM Injection Tech 3G 160 amp alternator, pulley
RJM Injection Tech mini starter
RJM harnesses and 2 gauge charge cable kit
Autometer gauges (soon)
Optima Battery.
ECU:
F.A.S.T. XFI
TUNING:
Naka'z Racing
|
Drivetrain: |
TRANSMISSION:
E4OD built by Naka'z Racing, Waipio, Hawaii
Precision Industries 10.5 inch Billet torque converter
Baumann Electronics Baumannator TCU and harness
Custom valve body
F350 trans oil cooler
T-CASE:
Borg Warner 1356
DRIVESHAFT:
Automotive Parts Unlimited 800 270-5224(Eric) 1350
Driveshaft
2.75 inch tube x .095 thick wall
Ford Super Duty 1350 Greasable U Joints
REAR END:
Currie Enterprises 8.8 w/ 9 inch large bearing ends
Currie 4:10 gears
Currie forged axles
Currie 11 in. drum brakes
Detroit Tru Trac
BFG AT 31 x 12.50 on 15 x 10 Weld Racing rims
LPW Ultimate aluminum cover w/ cap stabilizers
FRONT END:
Stock D44 TTB to be regeared w/ D50 stub/slip swap
Warn manual hubs
STEERING:
Saginaw pump swap (1991 E350 pump bracket)
Cardone pump
Borgeson 985 shaft (soon)
Red Head Steering Gears box (soon)
BRAKES:
F350 Hydroboost & MC upgrade w/ SS Braided hoses (soon)
SUSPENSION:
Stock height, springs, Edelbrock IAS shocks
|
Notes: |
Currant Red Silver Anniversary Edition. Built for daily driving on pump gas with occasional off roading for hog hunting, wheeling etc.. Displacement, cam profile, vehicle weight, tire height, gearing, highway cruise speed, all considered and spec'd for this truck by Dan Strezo. Small block snap, big block torque.
Special thanks to Allen Nakamura of Naka'z Racing who went 8.14 @168 mph on true 10.5s in a DLS powered turbo mustang.
Continuous work in progress.
|
