altcompare.jpg Alternator Comparison

With an external wire from the "S" terminal to the B  (output stud), the later PCM-controlled alternator will work on older cars if the correct connector & pinout are used.  '98-02 will require the LG/R wire to be moved; older will require the correct connector be spliced on.
