Featured Powerplant: Ford's Y-Block

Ford's Y-block

Closely based on the 317 cubic inch OHV engine introduced in the 1952 Lincoln, Ford's Y-block was introduced in 1954. Overall engine design goals included room for increased displacements and compression ratios. In addition, it was a modern short stroke design that reduced internal friction and piston speed to enhance durability. Low construction costs were a factor too. One example is that the Y-block required fewer casting cores than the flathead.

Ford's new engine family began with 239 and 256 cubic inch displacements. From the 239, a bore increase produced the 272 and 292 engines. This was followed by another increased bore and stroke to produce the 312. The Y-block was installed in Ford cars from 1954 to 1962 and Mercurys from 1954 to 1960. Starting in 1955, the Ford car base V8 was the 272 with the 292 optional in 1956 and 312 in 1957. Thunderbirds had the 292 in 1955, the optional 312 in 1956 and the 312 standard in 1957. Mercury moved from the 256 to the 292 in 1955 and the 312 became standard in 1956. Ford pickups used the 272, then the 292 until 1964. Ultimately, Y-blocks were phasaed out by FE engines starting in 1958.

Ford's Y-block

Performance development of the 312 peaked in 1957 with a centrifugal advance distributor, larger exhaust manifolds, improved intake manifold configuration and use of Holley's new 4150 series carburetor. Heads got larger intake valves and higher compression. Ford produced single four-barrel and dual four-barrel performance options along with the famous Thunderbirds. Race prepared Y-blocks powered Ford and Mercury NASCAR stock cars. After 1957, they were de-tuned for economy, although the big valve heads were retained through 1959.

Block, Crank, Rods and Pistons

The block was designed with an extended skirt design, which means it extended past the crank centerline. Viewed from the front, the block shape resembled a Y - hence the name. The extended skirt increased block rigidity and main web support. Additional defining Y-block features were the rear mounted distributor and external oil pump.

Ford's Y-block

Connecting rods were forged, and there were two different lengths. The 272/292 rods were 0.072-inch longer than the 312 rods. Rods were bushed for full floating piston pins that were retained by circlips.

Passenger car cranks were cast, while pickup cranks were forged. The major differences between the 272/292 and 312 cranks is the increased main journal diameter that was used on the 312. Rod journal diameters remained the same. On 312 blocks, the larger diameter main journal bore came awfully close to the main cap bolt holes. As a result, potential cracks could occur around the bolt holes when the main caps were torqued in place. Many builders used a 292 block (which could be opened up to a 312 bore) with a 312 crank with turned down mains for ultimate durability.

Intake, Heads and Valvetrain

Y-block heads had several unusual features. A major one was the stacked intake ports (unlike the conventional side-by-side 317 Lincoln port layout). This allowed the H-shaped intake to be less bulky. Also, the head port configuration supposedly introduced turbulence to the air/fuel mixture as it flowed through the port and entered the combustion chamber to burn at maximum efficiency. According to Y-block expert John Mummert, the revised ECZ-G heads were the best OE castings, thanks to even flow between intake ports.

Ford's Y-block

Another unusual feature was that all Y-blocks had a solid lifter cam using mushroom shaped lifters. Because oil gallies for hydraulic lifters were never cast in, it appears Ford never intended to install them.

Valves were operated by shaft-mounted rocker arms. rocker arm oiling occurred via a hole (later a groove in the cam journal), that directed oil through a passage in the block, head and rocker shaft stand. Due to lower quality oils, and lackadaisical oil changes by owners, this passage could become blocked by sludge, starving the rockers. When rebuilding a Y-block, it's important that these passages are clean.

Complete article now available in issue #3 of Legendary Ford Magazine

To read this article in its entirety, visit Legendary Ford Magazine online and subscribe today!


Ford's Y-block

Ford's Y-block

Note: SuperMotors has a business affiliation with Legendary Ford Magazine, which provides Ford, Lincoln, and Mercury articles and content to SuperMotors.

Back to the Issue #3 index.
