1992 Bird Sesshomaru

From 1994 Ford Thunderbird “RedThunder” — documented by RedThunder94.

67 photos
← Back to this vehicle
1994 Ford Thunderbird - A silver 1994 Ford Thunderbird is parked in a lot next to a building with a newspaper stand. 1994 Ford Thunderbird - Rear view of a silver 1992 Ford Thunderbird parked in a lot with a Kicker sticker on the rear window. 1994 Ford Thunderbird - Front view of a silver car with a hood ornament and Texas license plate. 1994 Ford Thunderbird - Interior door panel of a 1994 Ford Thunderbird, blue and silver accents. 1994 Ford Thunderbird - The interior door panel of a car is visible with the door open. 1994 Ford Thunderbird - here's a pic of my set of scott hrbaceks custom white faced bullitt style gauges, he has a wide range of different gauge faces for mn12's,… 1994 Ford Thunderbird - my cold air intake with a cone filter, it was relocated to redthunder recently, and replaced by the stock airbox of the 94. 1994 Ford Thunderbird - my old box, two gen 1 alpine type r subs. some of the first ones out. 1994 Ford Thunderbird - here's a pic from my first joint tccoa/fordbastards spring meet in austin in front of the oasis restaraunt, in 2004, had fun, although one… 1994 Ford Thunderbird - older pic, circa 2002-2003 1994 Ford Thunderbird - another oldie, circa 2002-2003 1994 Ford Thunderbird - here's a night shot. 1994 Ford Thunderbird - funny pic. a friend from the tccoa who is pretty good at photochop did this one for me, lol....:D 1994 Ford Thunderbird - this is the beginning of my series of pics depicting a swap to a later model 1994+ v6 130 amp alternator in my 1992 thunderbird that was or… 1994 Ford Thunderbird - rear of the 94+ alt shown on redthunder. 1994 Ford Thunderbird - here is a glimpse of what the wiring should look like for the big 3 upgrade. 1994 Ford Thunderbird - and another. 1994 Ford Thunderbird - here's the difference between the two alts, the wimpy early model 89-93 v6 70 amp alt is on the left, the better later model 94+ v6 130 amp… 1994 Ford Thunderbird - and another. 1994 Ford Thunderbird - here is the early (89-93) alt wiring harness. 1994 Ford Thunderbird - here is the 94 alt wiring harness, notice the difference. 1994 Ford Thunderbird - and another. 1994 Ford Thunderbird - here is the rear of the 94+ alt off the vehicle. 1994 Ford Thunderbird - here is the extension piece that must be added to the bracket so the later model alt will bolt up to the early model mount. 1994 Ford Thunderbird - here is the top view of the extension, this was made with a piece of heatshield that i had laying around. 1994 Ford Thunderbird - and another. 1994 Ford Thunderbird - again. 1994 Ford Thunderbird - another view. 1994 Ford Thunderbird - here is the new engine ground that was added as part of the big three upgrade. 1994 Ford Thunderbird - another view of the new engine ground. 1994 Ford Thunderbird - another view of the mess of wires that will be cleaned up later. 1994 Ford Thunderbird - tightening that new ground terminal. 1994 Ford Thunderbird - nice. notice the three wires going to the ground terminal, one is the regular factory ground, the other two are the new ones added for the… 1994 Ford Thunderbird - here is the spot that we made sure that it was nice and clean for the new chassis ground. 1994 Ford Thunderbird - here is the new nice and fat positive wire that will go directly to the positive terminal on the battery, to the left is the new engine gro… 1994 Ford Thunderbird - here is the positive terminal that now has a 4 ga supply from the alt. factory wires were ten gauge i believe so it should allow more curre… 1994 Ford Thunderbird - here is the big three starting to take shape, along with the newer more powerful alt. 1994 Ford Thunderbird - here it is in all it's glory, the big three, bigger engine ground, bigger chassis ground, and a bigger positive power supply from the alt t… 1994 Ford Thunderbird - and another. 1994 Ford Thunderbird - again. 1994 Ford Thunderbird - and again. 1994 Ford Thunderbird - here's another pic of the newer alt, the new ground, and the supply, are you confused yet? 1994 Ford Thunderbird - the ground, and the supply, different angle. 1994 Ford Thunderbird - here's the chassis ground. 1994 Ford Thunderbird - negative battery terminal. 1994 Ford Thunderbird - positive battery terminal. 1994 Ford Thunderbird - again. 1994 Ford Thunderbird - ground, supply, and ground. 1994 Ford Thunderbird - terminals. 1994 Ford Thunderbird - another view of teh big tree. it's almost time to turn on the juice and see what shakes loose, lol, :D 1994 Ford Thunderbird - again. 1994 Ford Thunderbird - again. 1994 Ford Thunderbird - here is the mod you have to do to the early alt harness to plug in the newer alt. you just cut the white with black stripe wire and install… 1994 Ford Thunderbird - here's another view. 1994 Ford Thunderbird - here's how you plug it in. 1994 Ford Thunderbird - this is the 5/16's by 6" bolt along with washers that were used on the bottom hole of the alternator mount. 1994 Ford Thunderbird - again. 1994 Ford Thunderbird - here's where it goes, you may or may not need it depending on if the original bolt will fit through the hole on the alternator. if it doesn… 1994 Ford Thunderbird - here's a closeup. 1994 Ford Thunderbird - here's the threads on that friggin' bolt, be sure to add threadlocker blue on this and all the other bolts. 1994 Ford Thunderbird - here is the bottom bolt installed. 1994 Ford Thunderbird - here's the nut. 1994 Ford Thunderbird - here's what we have at idle. keep in mind that this is with an underdrive crank pulley installed, so all the belt driven accessories are no… 1994 Ford Thunderbird - again. 1994 Ford Thunderbird - and again. 1994 Ford Thunderbird - and again. 1994 Ford Thunderbird - and mission complete....:D
