351w, k&n drop in, msd coil, motorsport wires, bbk shorty headers, bassani y-pipe, single 3" catback, 160 amp alternator, upgraded saginaw p/s pump, optima red top battery, york 210 OBA.
Drivetrain:
e4od, external trans filter, tranny cooler and gauge.
Rear 8.8 w/ detroit locker, 4.56 gears, sierra axles, welded axle tubes, T/A Girdle, relocated spring perches, reangled shock mounts.
Front TTB dana 44 w/ limited slip, C clip eliminated, dana 50 stub shaft, 4.56 gears, Warn premiums.
35 13.50 15 Toyo M/T's
Notes:
5.5" deaver front coils, super runner extended radius arms, knuckle under, deaver 5.5" rear leafs, rancho 9000's,
bronco 012.jpg 453 hits | 72.16 KB | Posted: 3/12/06 Bad pinion angle and vibration. I'm gonna have to do something about this.
bronco 009.jpg 426 hits | 72.24 KB | Posted: 3/12/06 After 6" lift with the same 33" tires, . It's a little high in the rear but when I get my custom rear bumper/tire carrier on it should be pretty level. It needs 35's
bronco 001.jpg 411 hits | 88.15 KB | Posted: 7/9/06 Dana 50 stub shaft. Sorry there are no more pics I did this mod the night before a wheeling trip so there was no screwing around. This is a very straigh forward mod. Just remove the hub,brakes, rotor, spindle and axle on the passenger side. I had alr...
bronco 011.jpg 364 hits | 71.99 KB | Posted: 3/12/06 Nuckle under is next.
bronco 001.jpg 295 hits | 69.61 KB | Posted: 3/31/06 Driver side before flip
bronco 008.jpg 290 hits | 59.67 KB | Posted: 3/12/06 TTB ready to go back in. New super runner radius arms attached. I replaced pivot bushings also while it was out.
