2012-08-05 10.12.49.jpg
636 hits | 41.32 KB | Posted: 2012-08-05
ready for install...
(Posted in: tfi conversion)

2012-08-05 09.22.15.jpg
631 hits | 67.59 KB | Posted: 2012-08-05
top view shows rubber plug from 460 wiring harness...
(Posted in: tfi conversion)

2012-08-05 09.21.53.jpg
1097 hits | 69.34 KB | Posted: 2012-08-05
302 tfi module mounted on 460 remote tfi housing...
(Posted in: tfi conversion)

2012-08-05 09.16.58.jpg
623 hits | 56.9 KB | Posted: 2012-08-05
to plug the slot in the 460 housing where the remote tfi wires used to run, I sacrificed the 460 wiring harness to use the factory plug...
(Posted in: tfi conversion)

2012-08-05 09.00.50.jpg
567 hits | 81.67 KB | Posted: 2012-08-05
302 inerds installed in 460 housing. you have to use the retaining arm from the 460 (short arm at top) because the 302 housing has a long arm that protrudes out the side of the housing....
(Posted in: tfi conversion)

2012-08-05 08.57.01.jpg
590 hits | 76.74 KB | Posted: 2012-08-05
hole is tapped, use 1/8 drill bit, then M4-70 tap...
(Posted in: tfi conversion)

2012-08-05 08.50.15.jpg
548 hits | 72.61 KB | Posted: 2012-08-05
first of many trial fits. also locating where to tap hole on left side...
(Posted in: tfi conversion)

2012-08-05 08.35.52.jpg
584 hits | 74.44 KB | Posted: 2012-08-05
hole is cut...
(Posted in: tfi conversion)

2012-08-05 08.23.19.jpg
605 hits | 81.27 KB | Posted: 2012-08-05
front view...
(Posted in: tfi conversion)

2012-08-05 08.23.08.jpg
487 hits | 81.59 KB | Posted: 2012-08-05
302 on left, 460 on right. need to cut hole in 460 housing for tfi module, also have to drill and tap 1 hole seen on left side of 302 housing...
(Posted in: tfi conversion)

2012-08-05 08.21.15.jpg
440 hits | 61.17 KB | Posted: 2012-08-05
shafts removed, appear to have the same top...
(Posted in: tfi conversion)

2012-08-05 08.20.27.jpg
836 hits | 77.07 KB | Posted: 2012-08-05
302 tfi distributor on left, 460 remote tfi on right...
(Posted in: tfi conversion)
