Album section

Disk Brakes

From 1999 Chrysler 300M “Black Betty”, documented by Truthworldwide.

18 photos
← Back to this vehicle
1999 Chrysler 300M - Wheel-off view of a surface-rusted brake rotor and five-lug hub with the wheel studs and center hub cap exposed, the caliper still mounted… 1999 Chrysler 300M - Close-up of a rear brake assembly with the rotor and hub exposed, showing the caliper bracket, mounting bolts, and a parking brake cable ro… 1999 Chrysler 300M - A dark, blurry underhood shot showing a black cast bracket and linkage assembly with a rod running out to a chrome-handled adjustable tool… 1999 Chrysler 300M - Under-car view of a front suspension with the brake caliper unbolted and hanging by a wire hook from the coil spring, keeping weight off th… 1999 Chrysler 300M - A rusty brake rotor lies removed on a garage floor next to a red shop rag, a brass drift punch and two retaining pins, with the car's expos… 1999 Chrysler 300M - Two new brake rotors sitting on flattened cardboard boxes on a concrete driveway, with a red can of CRC Brakleen brake parts cleaner positi… 1999 Chrysler 300M - Dim underside shot of a rusty disc brake caliper still on its mount, viewed through the wheel well with the brake pad backing plate and cal… 1999 Chrysler 300M - Grimy underbody close-up of a disc-brake caliper and its mounting bracket, heavily rusted and coated in grease, with a rubber boot visible;… 1999 Chrysler 300M - Tight, dim shot of a rusty brake corner with the caliper removed, showing the exposed wheel hub and bare bearing bore framed by the corrode… 1999 Chrysler 300M - A large gray C-clamp braced against a wood block is used to compress a rusty brake caliper piston on a car's rear disc brake during a brake… 1999 Chrysler 300M - Annotated how-to photo of two disc brake pads lying backing-plate-up on a speckled garage floor, with red arrows and text labeling "Shim pr… 1999 Chrysler 300M - A well-used tube of Sil-Glyde silicone brake lubricant sitting on a speckled gray countertop, its white label showing the red and blue AGS… 1999 Chrysler 300M - Four disc brake pads laid out on a speckled concrete floor, two showing worn friction material with a center rivet and two flipped to show… 1999 Chrysler 300M - Dark, blurry under-car shot of a brake caliper and bracket mounted to a rusty spindle, with the flexible brake hose and a coil-wrapped line… 1999 Chrysler 300M - A freshly installed brake rotor mounted on a five-lug hub with the wheel removed, photographed from the front with the caliper off and the… 1999 Chrysler 300M - Two rusty-headed brake caliper guide bolts laid on a speckled concrete floor next to a piece of scrap lumber, their smooth shanks and threa… 1999 Chrysler 300M - Annotated close-up of a suspension knuckle and brake caliper with two red arrows pointing at freshly greased points where yellow grease has… 1999 Chrysler 300M - Close-up of a disc-brake caliper pivoted open away from the rotor during pad service, with a red annotation arrow labeling the caliper's lo…
