Single-cylinder ATV engine removed and sitting on plywood in a c…

‹ ›

A single-cylinder ATV engine sits pulled out on a plywood board on a cluttered garage floor, its finned cylinder, rusty exhaust header and black clutch cover exposed with wiring still attached. A Werner ladder, extension cords, wrench set, fuel cans and a small turf tire fill the space around it; date stamp reads 07/04/2008.

AI caption May 2010 · Photo 2 of 89
