e40d_stuff

From 1995 Ford Bronco, documented by stumpjumper78.

62 photos
← Back to this vehicle
1995 Ford Bronco - Close-up view of a vehicle's transmission range sensor and its connecting linkage mechanism. 1995 Ford Bronco - An electrical connector with a tan multi-pin socket is attached to a metal component in this close-up view. 1995 Ford Bronco - 95 solenoid body connector 1995 Ford Bronco - 95 E4OD solenoid connector bore 1995 Ford Bronco - strans stand hoop mounted to trans on tailgate 1995 Ford Bronco - hooked to the lift 1995 Ford Bronco - on the lift swingin.... 1995 Ford Bronco - swingin some more, disregard the fella in the background 1995 Ford Bronco - up the hill 1995 Ford Bronco - hanging in the garage 1995 Ford Bronco - Transmission assembly suspended by straps and chains, likely for removal or installation. 1995 Ford Bronco - should have put a bigger eye on there or maybe a big chain link 1995 Ford Bronco - The U telescopes, SWEET 1995 Ford Bronco - still swinging 1995 Ford Bronco - Boltin up the engine stand flange 1995 Ford Bronco - still boltin it up 1995 Ford Bronco - My paper towel plugs, wife thought it was hilarious for some reason 1995 Ford Bronco - on the stand 1995 Ford Bronco - on the stand different angle 1995 Ford Bronco - another angle 1995 Ford Bronco - The hoist hook and eye of the stand were at just the wrong angle when I put U into the stand, and let all the weight down, so I had to pull… 1995 Ford Bronco - another angle standing on it's own 1995 Ford Bronco - loosen up the safety chain 1995 Ford Bronco - just another pick 1995 Ford Bronco - whoops 1995 Ford Bronco - On the stand waitin to get rebuilt 1995 Ford Bronco - diy trans pump puller 1995 Ford Bronco - A bearing puller tool is used to remove a bearing from a vehicle's transmission housing. 1995 Ford Bronco - A close-up view of a transmission component being worked on with a specialized tool. 1995 Ford Bronco - A specialized tool is used to remove a bearing from a transmission component. 1995 Ford Bronco - Tool being used to service internal components of a transmission housing. 1995 Ford Bronco - A close-up view of a vehicle's transmission or engine component, showing a rusty bracket and wiring. 1995 Ford Bronco - A bearing puller tool is used on a component of a vehicle's transmission. 1995 Ford Bronco - A bearing puller tool is used on a transmission part with a splined shaft. 1995 Ford Bronco - Tool used to press a bearing onto a transmission component. 1995 Ford Bronco - A close-up view of a metal component, possibly from a vehicle's engine or drivetrain, showing a drilled hole. 1995 Ford Bronco - A close-up view of a metal component, possibly from an engine, with a visible serial number. 1995 Ford Bronco - out_again, this sucks 1995 Ford Bronco - e4od out again from the side, still sucks 1995 Ford Bronco - leaked past gasket, pump to case bolts had backed out, and were only hand tight. 1995 Ford Bronco - forward clutch burn up pic 1 1995 Ford Bronco - forward clutch burn up pic 2 1995 Ford Bronco - forward clutch burn up pic 3 1995 Ford Bronco - forward clutch burn up pic 4 1995 Ford Bronco - forward clutch burn up pic 5 1995 Ford Bronco - forward clutch burn up pic 6 1995 Ford Bronco - forward clutch burn up pic 7 1995 Ford Bronco - Forward planetary in drum, internal splines are gone 1995 Ford Bronco - new forward planet w/ splines 1995 Ford Bronco - top side of drum old planet w/ carnage 1995 Ford Bronco - top side of new planet 1995 Ford Bronco - top side of old (left) new (right) 1995 Ford Bronco - close up -- top side of old (left) new (right) 1995 Ford Bronco - old planetary splines in hardened steel output shaft pic 1 1995 Ford Bronco - old planetary splines in hardened steel output shaft pic 2 1995 Ford Bronco - overdrive roller clutch pieces 1 1995 Ford Bronco - overdrive roller clutch pieces 2 1995 Ford Bronco - overdrive roller clutch pieces 3 1995 Ford Bronco - overdrive roller clutch pieces 4 1995 Ford Bronco - E4OD nearly empty case 1995 Ford Bronco - E4OD internals 1995 Ford Bronco - E4OD internals
