Cargo Cover Rebuild

From 1995 Ford Bronco “B'co” — documented by TRUCKY18.

11 photos
← Back to this vehicle
1995 Ford Bronco - This is my cover, and this is about as rolled up as it can get on its own, if you look closely you can see the safety pins holding the end… 1995 Ford Bronco - The first thing you have to do is take the end caps off. All you have to do is use a set of channel locks and hold the black rectangle and… 1995 Ford Bronco - This is a pic of the end cap after it has been turned. Now that the little thing which looks like an arrow is pointing at the middle of the… 1995 Ford Bronco - This is what is underneath. If all you need to do is re-tension it so it will roll itself up all you have to do is take both ends off. If y… 1995 Ford Bronco - This is the not-fun part, you have to push the black end down and remove the pin. Much easier said than done. The springs which push the en… 1995 Ford Bronco - This is the end with the 2 black pieces and the spring removed. They all shoot off as soon as you have the pin out so make sure you find al… 1995 Ford Bronco - This is the rod once it is removed, the spring on the left is the one that makes the cover roll itself up, it works just like a small versi… 1995 Ford Bronco - Here is the rod sitting beside the outer tube. The spring is held on to the rod with a small rivet, which luckily was in good shape. 1995 Ford Bronco - This picture shows how the little white parts sort of act as bearings for the rod, they only fit in one way and you can see the small dimpl… 1995 Ford Bronco - Now that most everything is back together you can re-tension the whole thing. This pic doesn’t show it but you have to roll the vinyl she… 1995 Ford Bronco - Now it rolls up just like it is supposed to. The next phase of the project is to address the ends where the vinyl is coming un-glued, espec…
