Epson R200 CIS

From 2004 Land Rover Land Rover “Random Pics”, documented by Steve83.

13 photos
← Back to this vehicle
2004 Land Rover Land Rover - I got this from Meritline for ~$100 on sale. 2004 Land Rover Land Rover - This is what's in the box. 2004 Land Rover Land Rover - After reading the included instructions, I decided to do it a LITTLE differently. First, I removed the cartridge cover so I could modify it… 2004 Land Rover Land Rover - The instructions say to run the tubes out the angled forward area of the cover, but I didn't want them to turn that far forward. 2004 Land Rover Land Rover - Using a Dremel-type tool, I carved a small notch into the side of the cover. Even if I removed the CIS, this would have no effect, and bare… 2004 Land Rover Land Rover - This just looks neater to me. 2004 Land Rover Land Rover - The instructions also say to route the tubes out the side of the outer cover, but I didn't like that either. So I removed it. 2004 Land Rover Land Rover - A little Dremelling later... 2004 Land Rover Land Rover - With the power off, the carriage can be slid fully to the LEFT (since I've decided to route the tubes out the RIGHT) to pull the tubes as f… 2004 Land Rover Land Rover - It took some tweaking to get them to sit flat without pinching the tubes, but they're clear of the sliding carriage, and they hold the tube… 2004 Land Rover Land Rover - It's almost invisible. Compare this to the first photo. The cover doesn't sit all the way down because there's no space between it & the to… 2004 Land Rover Land Rover - The tubes are long enough (with some to spare) to place the tanks on the left behind the white speaker on the left for the system below the… 2004 Land Rover Land Rover - Instruction sheets
