Album section

Trans Swap

From 1992 Ford Bronco “Street Queen”, documented by CrazyBRONCOguy.

26 photos
← Back to this vehicle
1992 Ford Bronco - Three-quarter front view of a lifted dark gray Ford Bronco inside a wood-framed garage, wearing a plated front bumper with an LED light bar… 1992 Ford Bronco - An automatic transmission pulled from a vehicle sits upside down on flattened cardboard on a garage floor, with fluid stains around it and… 1992 Ford Bronco - A cast aluminum bellhousing sits bolt-face-up on a workbench during a drivetrain swap, its bore, mounting bosses and dowel holes exposed. A… 1992 Ford Bronco - The interior floor of a vehicle appears wet and dirty, with debris scattered across it. 1992 Ford Bronco - Comparison of two transmissions, one appearing new and the other used, with a tire and wheel in the background. 1992 Ford Bronco - Tight close-up from underneath showing an engine mount bracket bolted between the frame perch and a blue-painted engine block, with the bel… 1992 Ford Bronco - A black torque converter is shown inside a cardboard box, likely for shipping or storage. 1992 Ford Bronco - Transmission and drivetrain components are visible in this close-up shot. 1992 Ford Bronco - Underside view of an automatic transmission bolted into a truck chassis, showing the cast aluminum bellhousing, finned pan and the transfer… 1992 Ford Bronco - The underside of a vehicle shows a transmission and exhaust system, with a portion of the frame and suspension visible. A red wire runs alo… 1992 Ford Bronco - The underside of a vehicle shows a silver transmission pan with fins and a drain plug. The pan is attached to the transmission with several… 1992 Ford Bronco - The underside of a vehicle, showing the rear axle, suspension components, and exhaust system. A blue aftermarket part is visible attached t… 1992 Ford Bronco - A box of AMSOIL Super Shift transmission fluid is shown in a storage area with wooden walls. 1992 Ford Bronco - An aftermarket finned transmission cooler mounted in front of the radiator and condenser behind a truck's front bumper and grille opening,… 1992 Ford Bronco - Close-up of a chrome-bezel mechanical pressure gauge with a white face, dual red psi and black bar scales reading to 250 psi / 16 bar, plum… 1992 Ford Bronco - A hand holds an engine vacuum and fuel pressure test gauge with a black face, marked in inches of mercury, cm Hg, kPa and psi, with the nee… 1992 Ford Bronco - An automatic transmission valve body removed from the vehicle and laid face-up on a light marble countertop, its cast aluminum casting stai… 1992 Ford Bronco - A clean, freshly rebuilt automatic transmission valve body sitting on a plastic bag, its bare aluminum casting bright with no fluid stainin… 1992 Ford Bronco - Close-up of a single black flange-head hex bolt lying on a textured paper towel, its threads visibly damaged and deformed along the lower h… 1992 Ford Bronco - A row of roughly a dozen black Amsoil synthetic motor oil quart bottles with blue caps lined up on a plywood garage shelf, alongside a blue… 1992 Ford Bronco - An electric cooling fan sits on a workbench next to shipping boxes and various gauges. 1992 Ford Bronco - The front bumper area of a vehicle is shown, featuring a winch mounted below the radiator. A portion of the front tire and suspension is vi… 1992 Ford Bronco - A close-up view shows a black electric fan mounted on top of a silver oil cooler, with a white oil filter to the left, all installed beneat… 1992 Ford Bronco - A silver skid plate is mounted to the undercarriage of a vehicle, extending forward from the front tire. The skid plate is secured by bolts… 1992 Ford Bronco - Driver-side 3/4 front view of a lifted 1990s Ford Bronco in flat/satin dark paint parked on grass, with a black tubular front bumper carryi… 1992 Ford Bronco - Close-up of an engine component with a braided hose attached, showing a red label.
