Overhead-cam V8 engine with timing covers off showing cam sprock…

Front view of a partially assembled overhead-cam V8 on a stand with the timing covers off, exposing both cam sprockets, the twin timing chains, orange and yellow chain guides and the crank sprocket. The heads are installed with intake ports open in the valley of the block.

AI caption January 2014 · Photo 2 of 1148
