What was the highest horsepower recorded on this dyno sheet?

DYNORUN.002 recorded the highest max power at 150.3 STD horsepower; DYNORUN.004 and DYNORUN.003 also reached about 150.0.

What was the maximum torque shown?

The highest max torque was 134.1 ft-lbs on DYNORUN.003. Other runs showed 132.6 (run 004), 130.0 (run 002), and 129.0 (run 001).

Who performed the dyno testing and when?

TMW Dyno Service's, phone (815) 521-1820, on 07/30/2005 between approximately 6:27 PM and 6:45 PM (four runs).

How many dyno runs are on this chart?

Four runs: DYNORUN.001, 002, 003, and 004, all overlaid on one graph of horsepower and torque versus RPM (1,500–8,000).

How consistent were the runs?

Very consistent — max power ranged from 147.5 to 150.3 hp and max torque from 129.0 to 134.1 ft-lbs across all four runs.

Home/ Registry/ Ford/ Focus/ 2003 Ford Focus/ Photo supermotors.net/registry/media/229930

2003 Ford Focus Dyno Chart - TMW Dyno 150 HP / 134 ft-lb, 4 Runs (2005)

TMW Dyno Service horsepower and torque dyno chart, four runs dated 07/30/2005

‹ ›

Chassis dyno graph from TMW Dyno Service showing four overlaid runs; max power about 150.0 hp and max torque about 132.5 ft-lb plotted versus RPM.

AI caption July 2005 · Photo 8 of 95

This document is a chassis dynamometer graph printout from TMW Dyno Service's (phone (815) 521-1820), dated 07/30/2005. It overlays four dyno runs (DYNORUN.001 through DYNORUN.004) recorded between 6:27 PM and 6:45 PM that day, plotting STD Horsepower (0–175 scale) and STD Torque in ft-lbs (20–140 scale) against engine RPM from 1,500 to 8,000. The legend reports peak values for each run: DYNORUN.004 made 150.0 max power and 132.6 max torque; DYNORUN.002 made 150.3 max power and 130.0 max torque; DYNORUN.003 made approximately 150 max power and 134.1 max torque; and DYNORUN.001 made 147.5 max power and 129.0 max torque. The curves show torque peaking in the mid-RPM range (roughly 3,500–5,500 RPM) and horsepower climbing to its peak near 6,000–6,500 RPM before runs end around 7,300–7,500 RPM. A reader can learn the run-to-run consistency (all four runs within about 3 hp of each other) and the overall power/torque characteristics of the tested vehicle. The document itself does not identify the vehicle, engine, or any modifications tested.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What was the highest horsepower recorded on this dyno sheet?: DYNORUN.002 recorded the highest max power at 150.3 STD horsepower; DYNORUN.004 and DYNORUN.003 also reached about 150.0.
What was the maximum torque shown?: The highest max torque was 134.1 ft-lbs on DYNORUN.003. Other runs showed 132.6 (run 004), 130.0 (run 002), and 129.0 (run 001).
Who performed the dyno testing and when?: TMW Dyno Service's, phone (815) 521-1820, on 07/30/2005 between approximately 6:27 PM and 6:45 PM (four runs).
How many dyno runs are on this chart?: Four runs: DYNORUN.001, 002, 003, and 004, all overlaid on one graph of horsepower and torque versus RPM (1,500–8,000).
How consistent were the runs?: Very consistent — max power ranged from 147.5 to 150.3 hp and max torque from 129.0 to 134.1 ft-lbs across all four runs.
