Close-up into an aluminum throttle body bore showing the brass t…

Close-up of an installed aluminum throttle body with the intake tube removed, looking straight into the bore at the brass-colored throttle plate and shaft, with the throttle position sensor, blue-anodized linkage spool, gold-plated cable bracket and return spring alongside. Yellow-labeled fuel injectors, wiring connectors and black hoses sit below on the intake manifold.

AI caption July 2007 · Photo 232 of 326
