Lincoln 3.0L V6 Engine Cutaway - Hydraulic Timing Chain Tensioner Locations

This document is a color cutaway illustration of a Lincoln V6 engine, shown from the front-left with the timing chain drive, camshafts, pistons, crankshaft, and accessory drive visible in transparent 'ghosted' style. The engine cover clearly bears the LINCOLN name. Two orange circles have been hand-drawn on the image at the front of the engine, marking components adjacent to the timing chains on each bank. Orange leader lines connect both circles to a handwritten-style caption reading 'hydrolic tentioners (remove boltes to loosen chain)' (sic — i.e., hydraulic tensioners; remove bolts to loosen chain). The image serves as a quick visual reference showing where the hydraulic timing chain tensioners are located and indicating that their bolts must be removed to relieve chain tension, presumably during timing chain or front-of-engine service. No part numbers, torque specifications, model years, or written procedure steps appear in the document; it is purely an annotated locator diagram. The filename supplied with the upload suggests it depicts a 3.0L V6 (MKZ), but no such text is visible in the image itself.
