Underside of a vehicle rocker and wheel arch with pitted underco…

Tight underside shot looking up into a wheel arch and rocker area, showing gray undercoating over pitted, blistering sheet metal with early surface corrosion along the pinch weld. A ribbed flexible conduit or hose and a perforated inner-fender/frame bracket with drain holes run along the lower right.

AI caption January 2011 · Photo 14 of 681
