Close-up looking straight down a two-stroke cylinder bore at the piston crown, with the exhaust port opening visible in the bore wall and transfer port cutouts at the sides. The piston top is cast with an 'EX' marking and a directional arrow and shows brown carbon/heat staining, with the crosshatch worn to a polished finish.
