-95 351W full roller motor
-Trickflow heads
-Fox body oil pan
-Holley 4DI injection system
-BC Broncos ceramic coated headers
-Super single - Magnaflow 2-2.25" in to 1-3"exhaust.
-V6 Explorer radiator
-Taurus Fan
-Full custom serp belt setup. Started as Explorer serp setup and migrated from there to incorporate Mark IV Saganaw pump.
Drivetrain:
-4R70W transmission Rebuilt by me!
-Braumantor TCS controller
-Dana 20-T transfer case
>>Tera Low 3.15:1 gears
>>Modified/ground shift rods for true twin stick operation
>>Wild Horses HD output shaft
>>Tom's Bronco parts Twin Stick
-Ford 9 inch rear axle with:
>>Strange radial ribbed econ-nodular iron case
>>Detroit NASCAR locker
>>Yukon alloy axles
>>Dana 4.88:1 gears
>>1.75" drum brakes
>>Shaved & trussed HD housing
-Dana 44 stock EB front axle with:
>>Detroit soft locker
>>Dana 4.88:1 gears
>>RCV axles & joints
>>30 spline Warn locking hubs with RCV 300M inserts
>>F150 disk knuckels
>>Rolled the knuckles 13° to correct the caster with 0° rubber C bushings
>>Extended radius arms built by me, simmilar to Lars Bars
>>Balistic rod ends for raduis arms
>>West Texas Off Road 1.5" ram assist
>>4x4x2 power steering box
>>Lincoln Mark IV Saganaw power steering pump w/HP output mod
>>Bilstein 12" short body resovour 7100 shocks
-Hydroboost brake system
-Summit "roll lock" brake line locks F&R
-4140 1.375" hex chromolly tie rod/draglink with 85 Shuvy ends
-5.5" BC Bronco front coil springs
-5.5" BC Bronco (Deaver) 11 leaf rear springs
-Fiberglass cowl hood
-Family roll cage
Notes:
Assembled in 6 weeks for Rubicon trip in 9/2003! Only part of original drive line that wasn't replaced at that point was the transmission. Also replaced the wire harness because the old harness was butchered beyond repair by the previous owner.
Future/in process modifications:
-Mount racing seats on cage mounts
-Cage tie-ins to frame
-Camouflage (gray tones)
-Ford EFI conversion
Trails conquered:
Rubicon 9/2003, 9/2004, 9/2005, 9/2006, 8/2007
Pismo 10/2003 to present!!
Fright night hungry valley ORVA 10/03 to 10/2010
Glamis 11/2003
Octillo Wells 12/31/03, 12/31/06
TDS Desert safari 1996-2012 (RIP Jim Kuns)
Truckheaven 1996-present
Dummont Dunes 4/2004, 2/2007
HIgh Desert Roundup 2004 2006 2008 2009
Armogosa sand dunes 12/2004
Bald Mountian - Moonlight Madness 7/2005, 6/2006, 6/2007
Duesy/Eirshim August 2007-2012
BBBB 2006-2011
Future trips planned:
Shaver lake area trails including Swamp Lake June 2012
Fourdyce & various destinations in Oregon August 2012
Cantina for the 'Con Sept 2012
Fright Night October 2012
