Underneath Pics

From 1989 Ford Bronco “Jim's 89 Bronco”, documented by Inactive Account.

18 photos
← Back to this vehicle
1989 Ford Bronco - Front spring view with the steering stabilizer. 1989 Ford Bronco - Dim view up into the front wheel well past the tread of an all-terrain tire, showing the front coil spring seated on the axle perch, the co… 1989 Ford Bronco - Underbody close-up of a cast radius arm bolted to the front axle housing, with its oval lightening window, mounting bolt heads and the axle… 1989 Ford Bronco - Underbody view of a truck's front suspension shot from ground level, showing the radius arm running rearward from the axle to its frame-sid… 1989 Ford Bronco - View from beneath the truck of the rear radius-arm mount where the arm passes through its bushing into a bracket on the frame crossmember,… 1989 Ford Bronco - This image shows the underside of a vehicle, focusing on suspension components and a portion of the tire. 1989 Ford Bronco - Rear axle shot 1989 Ford Bronco - Front axle. There's a small oil leak right now. 1989 Ford Bronco - Under-vehicle shot of a front suspension shock mount and radius arm, with a rusty forged arm running from the axle bracket toward the frame… 1989 Ford Bronco - Close-up view of the front suspension's coil spring and shock absorber, showing signs of rust and wear. 1989 Ford Bronco - rear shot 1989 Ford Bronco - Underside view of a solid front drive axle housing with its cast differential and lightening windows, a coil spring on the axle perch, a sh… 1989 Ford Bronco - rear diff shot 1989 Ford Bronco - rear leaf spring shot 1989 Ford Bronco - A close-up of a leaking component on the underside of a vehicle, with the Supermotors.net logo in the corner. 1989 Ford Bronco - Close-up looking down at a recirculating-ball steering gearbox mounted to the frame rail, with two curved metal hydraulic pressure and retu… 1989 Ford Bronco - This is a close-up view of a power steering component, likely from a vehicle's engine bay. 1989 Ford Bronco - Close-up view of the greasy underside of a vehicle, showing suspension components and a watermark.
