Blanco's eletrical

From 1990 Ford Bronco “BlancoBronco”, documented by Cam Correa.

19 photos
← Back to this vehicle
1990 Ford Bronco - Underside view of a painted vehicle frame rail showing mounting holes and a small brass fitting. 1990 Ford Bronco - Close undercarriage view of a vehicle's frame bracket with bolt holes and a protruding brass fitting. 1990 Ford Bronco - round white-faced pressure gauge mounted in a tight space behind a metal vehicle panel. 1990 Ford Bronco - engine bay fitted with a red Optima battery and a red ExtremeAire onboard air compressor. 1990 Ford Bronco - Engine-bay wiring detail showing a solenoid, relays, copper bus bars and colored wires near the firewall. 1990 Ford Bronco - solenoid, stacked relays and heavy battery cabling mounted along the firewall of an engine bay. 1990 Ford Bronco - engine bay showing a red Optima battery beside a red ExtremeAire air compressor with a finned cylinder. 1990 Ford Bronco - orange spring-loaded valve or actuator mounted in a dusty engine bay surrounded by rubber hoses and wiring. 1990 Ford Bronco - round dual-scale pressure gauge with a red dial reading near zero, mounted below a blue cylindrical air tank. 1990 Ford Bronco - bank of relays mounted on an aluminum panel with yellow, red and white wires, sitting inside a vehicle cabin. 1990 Ford Bronco - gray painted sheet-metal compartment with bundled colored wires feeding into a black weatherproof connector. 1990 Ford Bronco - aluminum control panel with eight labeled toggle switches (FT.LTS, REV.LT, AMBER, etc.) and pilot lights, held by hand. 1990 Ford Bronco - Close-up of a black compartment with a red battery cable, yellow wire and a purple relay mounted to a bracket. 1990 Ford Bronco - black cylindrical air tank mounted under a vehicle chassis with brass fittings and blue and black air lines. 1990 Ford Bronco - Underbody view of a black air reservoir tank with brass ports and routed blue and black air lines along the frame. 1990 Ford Bronco - brass valve assembly and an ARB-branded solenoid plumbed into a black air tank, mounted under a vehicle frame. 1990 Ford Bronco - Brass push-fit fittings and air lines connected to a black air spring bag mounted alongside a vehicle frame and axle. 1990 Ford Bronco - brass fitting on an air line routed through a black plastic fender liner above a chunky off-road tire. 1990 Ford Bronco - brass air-line fitting under a vehicle's black fender liner, with a knobby off-road tire visible below.
