What wire colors are on the cruise-only clockspring harness connector?

Black (Ground), Yellow/Light Blue Stripe (Horn), Black/Violet Stripe (Chime when Key In Ignition), and Blue/Black Stripe (Cruise).

What wire colors are on the plug under the dash that mates to the clockspring?

Black/Violet Stripe (Chime when Key In Ignition), Light Blue/Black Stripe (Cruise), Green/Orange Stripe (Ground), and Dark Blue x 2 wires (Horn).

Which wire is the horn circuit on the under-dash plug?

The horn circuit at the under-dash plug uses Dark Blue x 2 wires; on the clockspring harness side the horn wire is Yellow/Light Blue Stripe.

Which wire carries the key-in-ignition chime signal?

On both the clockspring harness and the under-dash plug, the chime-when-key-in-ignition circuit is the Black/Violet Stripe wire.

What is the ground wire color at the under-dash plug versus the clockspring harness?

Ground is Green/Orange Stripe at the plug under the dash and plain Black on the clockspring harness.

Home/ Registry/ Mercury/ Grand Marquis/ 1998-2011/ 1999 Mercury Grand Marquis/ Photo supermotors.net/registry/media/1102064

1999 Mercury Grand Marquis Cruise-Only Clockspring Wiring Pinout Diagram

Clockspring harness and under-dash plug connector pinout: horn, cruise, chime and ground wire colors

‹ ›

Connector face diagrams for a clockspring harness and under-dash plug listing terminal functions (horn, cruise, chime, ground) with their wire color codes.

AI caption December 2016 · Photo 1433 of 1442

This document is a hand-made wiring/pinout reference showing two four-pin connectors related to a steering-wheel clockspring installation, apparently for a cruise-control-only (non-redundant-controls) setup. The left diagram, outlined in red and labeled "Clockspring Harness," shows the connector on the clockspring side with four circuits and their wire colors: Ground (Black), Horn (Yellow/Light Blue Stripe), Chime when Key In Ignition (Black/Violet Stripe), and Cruise (Blue/Black Stripe). The right diagram, labeled "Plug Under Dash," shows the mating vehicle-side connector under the dash with the corresponding circuits: Chime when Key In Ignition (Black/Violet Stripe), Cruise (Light Blue/Black Stripe), Ground (Green/Orange Stripe), and Horn (Dark Blue x 2 wires). Pin positions are drawn schematically within each connector outline so a reader can match each cavity to its function and wire color on both sides of the connection. A reader can use this to identify which wire performs which function when swapping or wiring a clockspring for cruise control, horn, key-in-ignition chime, and ground on the associated vehicle. The document itself contains no year, make, model, or part number information; the vehicle attribution comes from the uploader's gallery (1999 Mercury Grand Marquis).

Is this accurate? Sign in to help verify it.

Frequently asked questions

What wire colors are on the cruise-only clockspring harness connector?: Black (Ground), Yellow/Light Blue Stripe (Horn), Black/Violet Stripe (Chime when Key In Ignition), and Blue/Black Stripe (Cruise).
What wire colors are on the plug under the dash that mates to the clockspring?: Black/Violet Stripe (Chime when Key In Ignition), Light Blue/Black Stripe (Cruise), Green/Orange Stripe (Ground), and Dark Blue x 2 wires (Horn).
Which wire is the horn circuit on the under-dash plug?: The horn circuit at the under-dash plug uses Dark Blue x 2 wires; on the clockspring harness side the horn wire is Yellow/Light Blue Stripe.
Which wire carries the key-in-ignition chime signal?: On both the clockspring harness and the under-dash plug, the chime-when-key-in-ignition circuit is the Black/Violet Stripe wire.
What is the ground wire color at the under-dash plug versus the clockspring harness?: Ground is Green/Orange Stripe at the plug under the dash and plain Black on the clockspring harness.
