Detailed underside shot of a solid front axle on a lifted 4x4, showing the cast knuckle and rusty disc brake caliper at left, the coil spring and its bucket with a limiting strap above, and two heavy black tubular radius arms bolting into the axle with a red polyurethane bushing. The differential housing and mud-terrain tire tread frame the shot on a concrete driveway.

AI caption July 2004 · Photo 85 of 144
