Two used dual-solenoid fuel-injection assemblies laid side by side on white paper for comparison, both on yellow zinc-plated steel mounting brackets. The unit on the right still has its black wiring connector and rubber fuel hoses attached, while the left one is stripped and shows green corrosion on the bracket.

AI caption June 2005 · Photo 737 of 3817
