Broken Ford manual hub. Wont allow the internal piece to engage, as it applies pressure to only one side of it.
The yellow line shows how the pressure plate is only receiving tension from one spring. I rebent the other spring and now just leave the hubs locked 24/7.
img_1788-edited.jpg | Hits: 587 | Posted on: 12/13/05 | View original size (521.58 KB)

Broken Ford manual hub. Wont allow the internal piece to engage, as it applies pressure to only one side of it.
The yellow line shows how the pressure plate is only receiving tension from one spring. I rebent the other spring and now just leave the hubs locked 24/7.
