Engine block deck with head removed, carboned pistons and green…

Close-up down onto an engine block deck with the cylinder head removed, showing four pistons still in their bores with heavy carbon buildup and pools of green coolant collected on the piston crowns. The steel head gasket is still laid on the deck and head bolts sit in the adjacent bank.
