Wide overhead view of a bare aluminum throttle body and upper intake elbow installed on a V8, with the throttle linkage, return spring and cables, a gold-plated bracket, the black EGR vacuum diaphragm at left and a red battery cable running across cleaned black wiring looms. The cowl vent panel and windshield wipers are visible at the top and the brake master cylinder reservoir sits at the right edge.

AI caption September 2006 · Photo 136 of 326
