Underside close-up of steering knuckle with tie rod end and brak…

Close-up under a vehicle showing a cast steering knuckle and hub area with the brake rotor edge and tire visible at left, and a heavy tie rod / drag link end with a large tapered stud passing through the arm at bottom right. A blue-painted casting and a red-coated component sit behind the knuckle, and the parts show surface rust and grease.

AI caption November 2006 · Photo 89 of 312
