What was the best dyno result on this sheet?

RunFile_005.dlf recorded the best numbers: 271.73 max power (hp) and 313.34 max torque (ft-lbs).

What were the results of all three dyno runs?

Run 003: 268.43 hp / 307.73 ft-lbs; Run 005: 271.73 hp / 313.34 ft-lbs; Run 006: 271.62 hp / 312.67 ft-lbs.

When and where were these dyno runs performed?

All three runs were done on 3/1/2006 (between 11:58 AM and 12:56 PM) at RWTD, 3016 Dauphin St., Mobile, AL 36606, phone (251) 479-9451.

What correction factor and conditions were used?

The SAE correction factor was used (SAE: 0.98) with smoothing set to 5. Run conditions ranged from 82.19–85.58 °F, about 30.24–30.26 in-Hg, and 22–26% humidity.

What was the air/fuel ratio at the cursor point (about 3,329 RPM)?

At X = 3.329 (3,329 RPM), the air/fuel readings were 13.23, 13.03, and 12.74 for the three runs, and the trace stays near 13:1 through the pull.

Home/ Registry/ Ford/ Mustang/ 1999-2004/ 2003 Ford Mustang/ Photo supermotors.net/registry/media/473717

2003 Ford Mustang Dynojet Dyno Sheet - 271.73 HP / 313.34 TQ (RWTD Mobile, AL)

Dynojet RWTD dyno chart, three runs ~268-272 hp / 308-313 lb-ft, Mobile AL

‹ ›

Dynojet rear-wheel power/torque dyno overlay of three runs (268-272 hp, 308-313 lb-ft) with air-fuel trace; shop at 3016 Dauphin St, Mobile AL.

AI caption January 2007 · Photo 89 of 127

This document is a Dynojet Research chassis dynamometer results sheet titled 'RWTD' from a dyno shop located at 3016 Dauphin St., Mobile, AL 36606, phone (251) 479-9451. It records three dyno pulls made on 3/1/2006 (RunFile_003, _005, and _006), all Run Type RO, with SAE correction factor (SAE: 0.98) and smoothing set to 5. The graph plots rear-wheel power (hp) and torque (ft-lbs) against engine speed from roughly 1,500 to 6,000 RPM, plus an air/fuel ratio trace along the bottom. Peak results: Run 003 made 268.43 hp / 307.73 ft-lbs; Run 005 made 271.73 hp / 313.34 ft-lbs (best run); Run 006 made 271.62 hp / 312.67 ft-lbs. Ambient conditions for each run are listed (82.19–85.58 °F, ~30.25 in-Hg barometric pressure, 22–26% humidity). A cursor at 3,329 RPM shows torque values of 295.76, 295.67, and 288.89 ft-lbs, power of 187.38, 187.33, and 183.02 hp, and air/fuel ratios of 13.23, 13.03, and 12.74 across the three runs. The A/F trace holds near 13:1 through the pull. Uploaded to a 2003 Ford Mustang gallery; the sheet itself doesn't identify the vehicle.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What was the best dyno result on this sheet?: RunFile_005.dlf recorded the best numbers: 271.73 max power (hp) and 313.34 max torque (ft-lbs).
What were the results of all three dyno runs?: Run 003: 268.43 hp / 307.73 ft-lbs; Run 005: 271.73 hp / 313.34 ft-lbs; Run 006: 271.62 hp / 312.67 ft-lbs.
When and where were these dyno runs performed?: All three runs were done on 3/1/2006 (between 11:58 AM and 12:56 PM) at RWTD, 3016 Dauphin St., Mobile, AL 36606, phone (251) 479-9451.
What correction factor and conditions were used?: The SAE correction factor was used (SAE: 0.98) with smoothing set to 5. Run conditions ranged from 82.19–85.58 °F, about 30.24–30.26 in-Hg, and 22–26% humidity.
What was the air/fuel ratio at the cursor point (about 3,329 RPM)?: At X = 3.329 (3,329 RPM), the air/fuel readings were 13.23, 13.03, and 12.74 for the three runs, and the trace stays near 13:1 through the pull.
