Tube-chassis mud truck front suspension with dual-rate coilover…
Close-up under a tube-chassis mud/race truck showing the front suspension: a coilover with stacked red and blue dual-rate springs on an adjustable shock mount, a red hydraulic ram steering cylinder on the tie rod, braided and blue-sleeved hydraulic lines, and black tube links running back to a driveshaft. A yellow plastic fluid jug is strapped inside the frame and a mud tire fills the left edge, with grass and event tents behind.
