Close-up of an alternator and wiring harness in an engine bay

Close-up down into an engine bay at a cast-aluminum alternator mounted on its bracket, with the serpentine belt and pulley at the bottom of the frame. A three-wire connector with orange and white leads plugs into the top of the case, surrounded by loomed harness, vacuum lines and a bare multi-pin connector at right.

AI caption March 2007 · Photo 21 of 81
