Inside a transmission extension housing showing the bronze tails…

‹ ›

Long Tailshaft HousingView all 8

Ford Genuine Parts label for one F5UZ-7A039-A transmission extension housing

Side view of bare aluminum transmission extension housing with cast W marking on a bench

Gray transmission extension housing gasket on cardboard labeled part number F7AZ-7086-A

Inside an aluminum transmission extension housing looking through to the bronze tail bushing

Aluminum transmission extension housing measured with a tape, cast F3UP-7A040-AA Ford marking

Output shaft seal and bronze bushing in a transmission extension housing tail

Ford aluminum transmission extension housing marked RF-F3UP-7A040-AA, passenger side

8photos in this albumView all

View looking down inside a cast aluminum transmission extension housing at the copper-colored bronze bushing pressed into the tail bore, with a dark seal visible just behind it. The rough as-cast interior walls of the housing frame the opening.

AI caption July 2007 · Photo 86 of 139

Is this accurate? Sign in to help verify it.
