Output shaft seal and bronze bushing in a transmission extension…

‹ ›

Long Tailshaft HousingView all 8

Ford Genuine Parts label for one F5UZ-7A039-A transmission extension housing

Inside a transmission extension housing showing the bronze tailshaft bushing and seal

Side view of bare aluminum transmission extension housing with cast W marking on a bench

Gray transmission extension housing gasket on cardboard labeled part number F7AZ-7086-A

Inside an aluminum transmission extension housing looking through to the bronze tail bushing

Aluminum transmission extension housing measured with a tape, cast F3UP-7A040-AA Ford marking

Ford aluminum transmission extension housing marked RF-F3UP-7A040-AA, passenger side

8photos in this albumView all

End-on view into the tail of an aluminum transmission extension housing, showing the output shaft seal with its light tan outer casing and the copper-colored bronze bushing seated deeper in the bore. A blue Genuine Ford Parts / Motorcraft box sits in the background.

AI caption July 2007 · Photo 91 of 139
