Cross-drilled front brake rotor and caliper on five-lug hub with…

Close-up of a front brake assembly with the wheel removed, showing a cross-drilled rotor on a five-lug hub with the two-piston caliper and pads still mounted. Behind it sit the coil spring, upper control arm and rubber-booted tie rod end; a red drain pan and jack stand are on the garage floor below.

AI caption December 2007 · Photo 14 of 50
