Leaf spring pack with U-bolts and shock, steel gauge hooked over…

‹ ›

Spring aligenmentView all 7

Under-truck view of a rusty rear leaf spring pack, frame rail and shackle by a mud tire

Bare rusty sheet metal floor bracing with drilled hole above gray carpet

Homemade U-shaped drilled steel bracket on a towel with a drill bit, motorcycle behind

Shop-fabricated square steel bracket with a bolt, on a towel beside a drill bit

Homemade steel gauge with threaded rod clamped over a truck's rusty leaf spring pack

Steel bar clamped in a red bench vise on a cluttered garage bench, motorcycle behind

7photos in this albumView all

Under-vehicle view of a multi-leaf rear spring pack with U-bolts and a shock absorber, with a small steel measuring gauge or fabricated tool hooked over the spring to check arch or ride height. The knobby shoulder blocks of a mud-terrain tire fill the left side of the frame.
