Close-up of splined transmission output stub shaft with bearing…

Close-up of splined transmission output stub shaft with bearing journal and green paint band

Close-up of a splined output/stub shaft laid on plastic sheeting, showing the machined bearing journal, a green paint or sealant band, helical gear-cut markings and the straight-cut splines at the tip. Part appears used, with light scoring on the shaft surface.

AI caption · Photo 89 of 98

Is this accurate? Sign in to help verify it.
