Comparison of 80-96 Dana 44IFS (TTB) spindles, showing differenc…

'80-96 Dana 44|FS (TTB) Spindles '80~91 except ~'91 ~94 ~'94-96 wldual I87'88 wlflange IOCKS Same overall height Same overall height Wheel seal Slot stops WIth threads Same thread depth Same thread depth Same outer bearing position V > Same outer bearing position Inner bearing 8" different Same inner bearing position Shoulder for Wheel seal 8" different . . r _ revised 77 W .. - , / ' I}? whee' sea' , _ 1," Same flange depth Same flange depth a Small ange with 6 small stud holes Large ange with 5 large stud holes_ Large ange with 5 large stud holes and 2 notches for 4WABS sensor and 2 notches for 4WABS sensor
