Ford V8 engine bay showing air intake tube, throttle body, EGR v…
new engineView all 3
Detail of a dusty fuel-injected Ford V8 engine bay, showing the ribbed rubber air intake tube feeding the throttle body, a black upper intake plenum, the EGR valve and its bracket, and the alternator low in the frame. A Ford-labeled black canister sits at left with vacuum lines and wiring harness routed across the engine, and a hose carries a blue inspection tag marked 71317.
