here is the connector view of the 98-04 interlock also used on s…

here is the connector view of the 98-04 interlock also used on sport models 05-07, pin 3 is powered in run and will need to be connected to a source for the 05 interlock to work correctly.

Owner caption April 2013 · Photo 25 of 77
