Album section

SAS

From 1987 Ford Bronco “Money Pit”, documented by Spectre.

9 photos
← Back to this vehicle
1987 Ford Bronco - Low-angle view under the front of a lifted truck showing a solid front axle with red-painted radius arm brackets, a red coil spring, white-… 1987 Ford Bronco - Under-truck view of a solid front axle with a black cast center housing, red-painted spring perch and knuckle brackets, a red coil spring,… 1987 Ford Bronco - Tight underbody close-up of a truck frame rail and body mount bolt, with a black radius arm running down to a red-painted axle-side bracket… 1987 Ford Bronco - Underbody close-up of a lifted 4x4 front suspension: a red-painted radius arm bolts to the axle end beside a white-bodied coilover-style sh… 1987 Ford Bronco - Tight underbody shot of a red-painted fabricated bracket bolted to the frame, with a large bolt and washer through its lower boss and a sma… 1987 Ford Bronco - Underside view of a truck showing a red-painted frame-mounted radius arm bracket bolted to the boxed frame rail, with a spade-and-pin-up-gi… 1987 Ford Bronco - Close-up under a truck showing a heavy black steering drag link or tie rod with an adjuster sleeve and clamp bolt, running past a red coil… 1987 Ford Bronco - Underside view of a lifted truck's front end showing heavy black radius arms running from the frame to a black solid axle with red-painted… 1987 Ford Bronco - Underbody view of a lifted truck's front suspension showing a black track bar mounted between red-painted frame and axle brackets, a red co…
