Red radius arm and red coil spring over white shock on a lifted…

‹ ›

SASView all 9

Solid front axle with red coils, white shock and steering stabilizer under a lifted Ford truck

Solid front axle with red coil spring, white shocks and red-painted brackets under a lifted truck

Underbody close-up of frame mount, black radius arm and red suspension brackets on lifted truck

Red fabricated suspension bracket bolted to a rusty truck frame with large through-bolt

Red radius arm and frame bracket with spade decal under a lifted truck's front suspension

Underbody close-up of black tie rod adjuster sleeve beside a red coil spring

Lifted truck front axle underside: black radius arms, white steering stabilizer, red coil spring

Black track bar between red brackets under a lifted truck, with coil spring and radius arm

9photos in this albumView all

Underbody close-up of a lifted 4x4 front suspension: a red-painted radius arm bolts to the axle end beside a white-bodied coilover-style shock with a red coil spring, black differential housing and tie rod at left, and a deep-lug mud-terrain tire at right. Shot from ground level on a dirt shop floor.

AI caption November 2007 · Photo 156 of 295
