this is my intake ducting with a MAF sensor right in the middle…

this is my intake ducting with a MAF sensor right in the middle of two 90 degree elbows. these sharp elbows create turbulance and uneven airflow in the ducting which will cause the MAF sensor to read inaccuratly and have 'noise' in the signal

the MAF is a 75mm Pro-M Bullet housing
