Where is the 7-pin trailer tow connector on the Ford Explorer rear end diagram?

The 7-pin trailer tow connector is identified as C4099, located near the center of the rear bumper area; the 4-pin trailer tow connector is C439 nearby.

What are the connector numbers for the Explorer's rear parking aid sensors?

C4009 (outer left), C4010 (inner left), C4011 (outer right), and C4012 (inner right).

What connector serves the left Side Obstacle Detection (SOD-L) module?

C4369 is the connector for the Side Obstacle Detection control module – Left (SOD-L).

Which connectors relate to the rear active park assist system?

C4420 is the rear active park assist sensor LH and C4421 is the rear active park assist module RH.

What splices are shown in the rear end area?

Splices S400, S401, S402, S403, S404, S405, S406, and S407 are called out in the rear bumper/liftgate harness area.

Home/ Registry/ Ford/ Explorer/ 2011-2019/ 2016 Ford Explorer/ Photo supermotors.net/registry/media/1172220

Ford Explorer Rear End Connector Locations - Parking Aid, Trailer Tow, SOD Diagram

Rear-end component-location diagram with connector and sensor callouts on vehicle outline

‹ ›

Service-manual component-location diagram showing rear connector and sensor positions

AI caption March 2024 · Photo 18 of 40

This document is a component/connector location diagram (schematic locator page) titled "Rear end," showing the rear view of a Ford Explorer (the word "EXPLORER" is visible on the liftgate). It uses a lettered/numbered grid border (rows A–F, columns 1–8) typical of Ford wiring diagram locator pages. Callout arrows identify the physical locations of rear-mounted electrical connectors, splices, and harnesses, including: rear active park assist module RH (C4421) and sensor LH (C4420); parking aid sensors — inner right (C4012), inner left (C4010), outer right (C4011), outer left (C4009); trailer tow connectors 4-pin (C439) and 7-pin (C4099); hands free (liftgate) actuation module (C4401); Side Obstacle Detection control module – Left (SOD-L) connector C4369; connectors C465, C405, C406; harness identifiers 14F238 and 14N139; and splices S400–S407. A reader can use this page to locate these connectors and splices on the rear bumper/liftgate area for diagnostics of parking sensors, blind-spot (SOD) modules, trailer tow wiring, and hands-free liftgate systems. The page was photographed upside down and has a shadow across part of the image, but the callout text is legible.

Is this accurate? Sign in to help verify it.

Frequently asked questions

Where is the 7-pin trailer tow connector on the Ford Explorer rear end diagram?: The 7-pin trailer tow connector is identified as C4099, located near the center of the rear bumper area; the 4-pin trailer tow connector is C439 nearby.
What are the connector numbers for the Explorer's rear parking aid sensors?: C4009 (outer left), C4010 (inner left), C4011 (outer right), and C4012 (inner right).
What connector serves the left Side Obstacle Detection (SOD-L) module?: C4369 is the connector for the Side Obstacle Detection control module – Left (SOD-L).
Which connectors relate to the rear active park assist system?: C4420 is the rear active park assist sensor LH and C4421 is the rear active park assist module RH.
What splices are shown in the rear end area?: Splices S400, S401, S402, S403, S404, S405, S406, and S407 are called out in the rear bumper/liftgate harness area.
