What circuit is on pin 16 of connector 14A005?

Pin 16 carries circuit GD348 (BK-YE wire). On the 14A005 side it is 12 gauge; on the 14N139 side it is 20 gauge.

Which pins are unused on connectors 14A005/14N139?

Pins 1, 6, 7, 8, 9, 14, and 15 are shown with no circuit assigned (dashes in the table).

What wire color is circuit VDB06 and which pins does it use?

VDB06 is gray-orange (GY-OG) and appears on pins 4 and 5, in 18 gauge on the 14A005 harness and 20 gauge on 14N139.

What circuit and wire color are on pin 2?

Pin 2 carries circuit CPK52 with a violet-white (VT-WH) 20-gauge wire.

What are the DUMMY circuits in this connector?

The 14A005 side lists black (BK) 18-gauge dummy wires: DUMMY11 on pin 4, DUMMY14 on pin 5, DUMMY12 on pin 12, and DUMMY13 on pin 13.

Home/ Registry/ Ford/ Explorer/ 2011-2019/ 2016 Ford Explorer/ Photo supermotors.net/registry/media/1172219

Ford Connector Pinout 14A005 / 14N139 - 16-Pin Wiring Circuits & Wire Colors

Male and female connector views with pin, circuit, gauge and wire-color chart

‹ ›

Connector pinout chart with male and female views and color-coded wire circuit listings

AI caption March 2024 · Photo 17 of 40

This page from a Ford wiring diagram manual documents a mating pair of 16-pin electrical connectors identified by harness numbers 14A005 (male) and 14N139 (female). Two connector face-view illustrations show the cavity numbering for both halves: pins 1–8 in one row and 9–16 in the other, mirrored between the male and female connectors. A pinout table lists, for each pin position, the circuit designation with wire color code, wire gauge, and a qualifier indicating which harness (14A005 or 14N139) the entry applies to. Populated circuits include CPK52 (violet-white, 20 ga) on pin 2, SBP10 (yellow-red, 20 ga) on pin 3, VDB06 (gray-orange) with DUMMY11/DUMMY14 (black) leads on pins 4 and 5, CRB04 (yellow-green, 18 ga) on pin 10, CBB21 (blue-gray, 18 ga) on pin 11, VDB07 (violet-orange) with DUMMY12/DUMMY13 (black) on pins 12 and 13, and ground circuit GD348 (black-yellow, 12 ga on 14A005 side, 20 ga on 14N139 side) on pin 16. Pins 1, 6–9, 14, and 15 are unused. A reader can use this page to identify wire colors, gauges, and circuit names when diagnosing or repairing this connector pair.
