Disassembled distributor on concrete with drive gear, reluctor w…

A disassembled distributor laid out on a concrete floor, with the aluminum housing and drive gear at top and its ignition control module bolted to the side. Below sit a spare drive gear, the toothed reluctor/armature wheel, and the stator pickup coil with its red and black wiring pigtail, dated 2005 8 15.
