V8 engine with intake manifold removed, exposing open cylinder h…

V8 engine bay with the intake manifold pulled off, exposing the open cylinder head intake ports on both banks and the green coolant residue pooled in the valley. Fuel rails with yellow-topped injectors are laid aside on the fenders, with the EGR valve, belt tensioner and crank pulley visible.

AI caption November 2006 · Photo 66 of 304
